2D-Disdrometer
2D-Disdrometer
This laser based instrument measures the size, shape, and distribution of incoming weather phenomena such as rain and snow.
It is equipped with space technology-driven software for clear visualizations.
Performance
ㆍMeasurement range
ㆍParticle size – 0.15mm~25mm
ㆍParticle velocity – 0.15m/s~25m/s
ㆍTransmitter – Laser diode, 650nm, 50mW
ㆍReceiver (detector) – Line scan camera
ㆍResolution – 512pixcel
ㆍLine rate – 98kHz
ㆍMeasuring area – 100cm2
Parameter
ㆍ8 type of precipitation (drizzle, drizzle/rain, rain, mixed rain/snow, snow, snow grains, freezing rain and hail)
ㆍRadar reflectivity Z
ㆍRain rate
ㆍParticle size distribution (32 size classes)
ㆍParticle velocity (32 velocity classes)
ㆍNumber of density
ㆍParticle aspect ratio
